Chapter 2. Hardware Setup
13
7. Connect USB peripherals (keyboard, mouse, flash drive, etc.) into their
respective USB Type-A ports on the CE840L and CE840R. To switch to a
different control mode, use the auto / local pushbutton (CE840L) and auto
/ remote pushbutton (CE840R). For more information, see USB Control
Modes, page 16.
8. Connect the microphone and speakers into their respective audio jacks on
the CE840L and CE840R.
9. To provide network access to the PC, connect a network switch to the
Ethernet port on the CE840R via an Ethernet cable.
10. To use the wake up PC pushbutton, use an RS-232 serial cable to connect
the RS-232 serial port on the CE840L to the local computer.
11. To control a local computer with a serial device, connect the RS-232 serial
port on the CE840L to the local computer as illustrated in step 10, and then
connect a hardware / software controller to the RS-232 serial port on the
CE840R.
Note: The RS-232 serial port supports bi-directional transmission.
12. (a) Connect one of the supplied power adapters into a power source, and
then connect the adapter’s power cable to the power jack on the CE840L.
(b) Connect the second power adapter into a power source, and then
connect the adapter’s power cable to the power jack on the CE840R.
