3-9ASUS PA32UCG Series LCD Monitor
• PBP Source: Selects the video input source from among HDMI-2, HDMI-
3, DisplayPort, and Thunderbolt. The table below shows the input source
combinations.
Main-window
Sub-
window
HDMI-2 HDMI-3 DisplayPort Thunderbolt
HDMI-2 Yes Yes Yes Yes
HDMI-3
Yes
Yes Yes
Yes
DisplayPort Yes Yes Yes Yes
Thunderbolt Yes Yes Yes Yes
HDMI-1 port does not support the PBP function. When DisplayPort 1.4 DSC is
selected in the DisplayPort Stream menu, DisplayPort does not support the PBP
funciton.
• Color Setting: Selects an individual Splendid Mode for the selected PBP
source. (Up to 2 Splendid Modes can be chosen.)
7. Input Select
In this function, you can select your desired input source.
ASUS PA32UCG
Standard Mode DisplayPort 3840 x 2160@ 120Hz
Input Select
HDMI-1 (v2.1)
HDMI-2 (v2.0)
HDMI-3 (v2.0)
DisplayPort
Thunderbolt
If one Thunderbolt port is plugged. the other one outputs DisplayPort signal
only.
When PBP is enabled, HDMI-1 (v2.1) is not available.
