3-7ASUS PA32QCV Series LCD Monitor
4. PIP/PBP
The PIP/PBP menu allows you to open up another sub-window connected
from another video source (when input source is below 60Hz) besides the
main-window from your original video source.
To activate this function, you need to do the following: turn off
MediaSync/
Dynamic Dimming
and disable HDR on your device.
PA32QCV
6016 x 3384_60Hz
Preset
Native
Input
Thunderbolt
Brightness
200
ExitBack Enter
Preset
Palette
PIP Size
PIP/PBP
Mode
Source
Color Setting
Volume 50
QuickFit Plus
ASUS DisplayWidget Center
• Mode: Selects PIP, PBP, PBP x 3 function, or turn it off.
To scale both displays to full screen in PBP mode, set resolution
settings for both as 2560 x 2880 in OS display settings. (And make
sure that the scaling option is "Maintain Display Scaling" if you are
using an Intel graphic card.)
• Source: Selects the video input source from among HDMI,
DisplayPort and Thunderbolt.
• Color setting: Select color Preset for Main and Sub windows.
• PIP Size: Adjusts the PIP size to Small, Medium or Large (Only
available for the PIP mode).
