4. Fan and Pump headers
The Fan and Pump headers allow you to connect fans or pumps to cool the system.
CPU_FAN
CPU_OPT
W_PUMP+
CHA_FAN1
CHA_FAN2
CHA_FAN3
CHA_FAN4
CHA_FAN5
CAUTION!
• DO NOT forget to connect the fan cables to the fan headers. Insufficient air flow inside the
system may damage the motherboard components. These are not jumpers! Do not place
jumper caps on the fan headers!
• Ensure the cable is fully inserted into the header.
IMPORTANT! For water cooling kits, connect the pump connector to the W_PUMP+ header.
NOTE:
• When connecting a single CPU fan, you may connect it to either the CPU_FAN or CPU_OPT
header.
• When connecting two CPU fans, ensure to connect the fans to the CPU_FAN and the CPU_OPT
header, and make sure both fans are the same brand and model.
• W_PUMP+ function support depends on water cooling device.
Header Max. Current Max. Power Default Speed Shared Control
CPU_FAN 1A 12W Q-Fan Controlled A
CPU_OPT 1A 12W Q-Fan Controlled A
CHA_FAN1 1A 12W Q-Fan Controlled -
CHA_FAN2 1A 12W Q-Fan Controlled -
CHA_FAN3 1A 12W Q-Fan Controlled -
CHA_FAN4 1A 12W Q-Fan Controlled -
CHA_FAN5 1A 12W Q-Fan Controlled -
W_PUMP+ 3A 36W Full Speed -
