4
Specications
Dimension
160 (L) x 80 (W) x 32 (H) mm
Cable length
650mm
Weight
Main product: 514 ± 5g; Docking stand: 95 ± 5g
Adapter without power cord: 330 ± 5g
Upstream
port
1 x USB 3.2 Gen 2 (10Gbps) Type-C® cable with Power Delivery up
to 90W (5.0V/ 9.0V/ 15.0V 3.0A, up to 20.0V 4.5A 90.0W)
Downstream
ports
Front
1. 3.5mm audio combo jack
2. USB 3.2 Gen 2 Type-A port
(10Gbps/5.0V 2.4A)
3. USB 3.2 Gen 2 Type-C® port
(10Gbps/5.0V 3.0A)
4. Smart card reader, SD4.0,
UHS-II
5. Power Key & LED indicator
Back
6. USB3.2 Gen 1 Type-A ports
(5Gbps)
7. RJ-45 port (10/100/1000 Mbps)
8. USB 3.2 Gen 2 Type-C® port
(DP1.4)
9. HDMI™ 2.0 port (3840 ×
2160@60P)
10. DisplayPort 1.4 port (3840 ×
2160@60P)
11. Power (DCIN) jack (20.0V
7.5A, 150.0W)
12. Kensington® lock
Operation
temperature
0 °C ~ 35 °C
Storage
temperature
-30 °C ~ 70 °C
Supported
Operating
System
Windows® OS (Windows® 10 or above)/MacOS
Display
resolution
Single display: up to 4K@60Hz / Dual display: up to 4K@60Hz
Triple display: up to 4K@30Hz
* It’s recommended that you connect screen from the low
resolution one.
** As some MACs do not support MST function, please contact
the manufacturer for more details.
*** When the DSC (Display Stream Compression) standard of your
device and monitor supports a compression ratio of 3:1, the
dock supports a resolution of up to 4K@60Hz in dual display
mode (USB-C® + HDMI™ 2.0 or USB-C® + DisplayPort 1.4) and
supports up to 4K@30Hz in triple display mode.
**** Both modes support the MST function and are backward
compatible.
ASUS Triple Display USB-C Dock
LED indicator
Dock with adapter Notebook status Power Key Status
Connected to power
supply
N/A
Solid orange
Shutdown (S5)
Hibernate (S4)
Suspend (S3)
Powered on Solid white
Disconnected from
power supply
N/A
O
Shutdown (S5)
Hibernate (S4)
Suspend (S3)
English
