14
You do not need to press the STORE button to save Utility parameters, it is done
automatically when you exit Utility Mode.
To exit Utility Mode, press the Utility button to return to Edit Mode.
PROGRAMMING HINT: Press the Value button to change and view the parameters then
use the Encoder to set the value. This way you don't have to switch between the
Param and Value buttons to edit values.
BYPASS LEVEL [100%]
[0 to 100%] or [= MIX DRY LEVEL]
You may globally control the level of the signal of the Bypass signal when you
bypass the ALPHA 2.0. The Bypass Level Utility parameter overrides whatever "DRY"
level of the Mix set in each preset. Every time you Bypass the ALPHA 2.0, the
through signal level will be whatever this value is set to. The initial default
setting is 75%.
When the value is set to [= MIX DRY LEVEL], the DRY level setting (from the
Programmable Mix) of the individual preset will be the signal level when the
ALPHA 2.0 is bypassed. Set your Bypass Level to avoid wild jumps in volume when
kicking the ALPHA 2.0 in and out.
REMOTE SWITCH 1 & 2
[= BYPASS ON/OFF]
The REMOTE jacks may be programmed to either Bypass the ALPHA 2.0, access the
Increment or Decrement Preset mode, and Re-Arm or Trigger the Sampler. A
footswitch and any two conductor cable is intended to be used with these jacks.
If you are using an ART X-15 ULTRAFOOT, you can use the Bypass Jack feature on
the X-15 to control one of the ALPHA 2.0's Remote Jacks. A momentary (normally
open) switch should be used in applications other than the X-15's bypass feature.
Use the following chart to determine how the Remote Jacks may be programmed.
# REMOTE 1 REMOTE 2
0 BYPASS ON/OFF BYPASS ON/OFF
1 SAMPLE-TRIGGER SAMPLE-TRIGGER
2 INCR PROGS 2 SAMPLER-ARM
3 N/A (no value) DECR PROGS
Either jack may be programmed for the Bypass feature, each time the footswitch is
activated (hot connected to ground) the BYPASS function is accessed and acts like
the Bypass button on the front panel.
The jacks may also be programmed to allow a footswitch to be used for accessing
either the Trigger or Re-Arm function when using the Sampler program. Either
