9
name. The LED associated with the button will flash to indicate you are in the
bypass mode. Pressing BYPASS again returns the unit to the ACTIVE mode indicated
by the display [ ****ACTIVE****] for about two seconds and then just displaying
the preset name and effects. Bypass level is determined by the Bypass Level
parameter discussed in the Utility section.
NOTES:
1) If the MIX parameters are programmed DRY = 0% and EFX = >0% and the Bypass
Level Utility parameter is set to =MIX DRY LEVEL and BYPASS is initiated, no
signal will be present at the outputs.
2) If the DRYEQ is set at any level greater than 0% and Bypass is engaged, the EQ
is "zeroed" and a "flat" signal is present at the outputs. This holds true even
if DRY is set to 0%.
EDIT MODE
EDIT MODE is engaged when you press the EDIT MODE button. All creation of presets
or preset parameter editing is done while in this mode. Titles, MIDI parameters,
and Utilities are all accessed in Edit Mode. When in Edit Mode, all buttons
associated with white lettering are active. All the control buttons work as well.
You may access all two hundred presets for modification or use while in Edit
Mode. Edit Mode is automatically entered when you press either the PARAM or VALUE
buttons.
Previewing Presets
You may preview presets while in Edit Mode by engaging the PRESET button. Use the
Encoder to scan through the presets. Only the titles of the presets are shown, so
it is helpful to know the contents. The processed output signal is not affected.
To recall the preset when you are ready, press the RECALL button. Signal is being
processed through the last active preset. The reason for this is so you can set
up for the next preset change when you want it to happen. When you stop scanning,
the preset number in the Seven Segment Display will be flashing. If RECALL is
pressed, the display will stop flashing indicating the preset is now active.
EDIT MODE CONTROL BUTTONS
ENTER
Use the ENTER button when you want to complete an action such as adding an effect
to a preset. When adding an effect there is a [?] after the name, press enter if
you wish to insert this effect into your chain. A prompt (i.e. [ADD EQUALIZER?])
will appear in the LCD when it is necessary to press Enter to complete a task.
RECALL
The RECALL button is used to Recall presets while you are in Edit Mode. To Recall
a preset (the Seven Segment Display will be flashing a Preset number), select the
proper Preset and press the RECALL button. If you have been editing the
parameters in a preset and wish to return them all to the original settings,
press the Recall button.
ADD EFFECT
Pressing the ADD EFFECT button once opens the Add Effect function.
