Je bekijkt pagina 29 van 40
DMX | 6
L-SeriesPlus User Manual 29
To Load a DMX Preset List:
1) Connect an USB memory stick to the USB-A connector of the L-Series Plus.
2) Push MENU (10) to open the menu.
3) Turn and push the encoder (4) to open the menu USB Functions -> DMX Presets -> Load DMX
Preset.
4) Turn and push the encoder (4) to set the DMX preset list. Set Yes to confirm the setting. Set No
to cancel the procedure.
5) The DMX preset list will be loaded in the device. It overwrites the DMX settings of the device.
6.10 DMX Monitor
When valid control data is received, the L-Series Plus automatically opens page one of the DMX
monitor in the display. The top right corner will say DMX, and the top left corner will note any special
settings, such as RGBW cal., when they are started.
In addition, there is a second page on the display that shows various values and parameters of the
device. DMX values are not listed here, instead, aspects such as intensity and CCT are written as
plain text. This is a useful function for troubleshooting in a control network.
Turning the encoder switches between the pages. The length of page two will vary depending on
what mode and values are being sent.
Information displayed on page one:
• DMX mode and description
• DMX address and channels used
• DMX footprint size
Information displayed on page two
The information displayed on page two of the DMX monitor is dependent on the active DMX mode:
DMX mode utilizing... Information
All DMX modes Intensity
Cross-fade, if active X-Fade (cross-fade)
Note: If the X-Fade is at 0 or 255, only the active
color control information will be displayed.
CCT CCT +/- Green
RGBW Red
Green
Blue
White
H S I Hue Sat
Gels (Base) CCT
Color Match
Brand
Cat. (Category)
Name
No. (Gel Number)
X-Trans (Transition
Type)
XY x Value
y Value
X-Trans (Transition Type)
Source matching Cat. (Category) Source
Up to 7 additional parameters can be displayed, depending on which effect is active. See the L-
Series Plus DMX Protocol Specification document for more information.
