6 | DMX
28 L-SeriesPlus User Manual
6.8 DMX Presets
The L-Series Plus supports 10 user-defined DMX presets with the following parameters:
• DMX Adress
• DMX Mode
• DMX ECC Channels
• Artnet / sACN State
• Merge mode
• Art-Net universe (if applicable - Not visible for sACN)
• sACN universe (if applicable - Not visible for Artnet)
• Art-Net Net (if applicable - Not visible for sACN)
• Art-Net Subnet (if applicable - Not visible for sACN)
• DMX Gateway
• DMX Loss Behavior
• DMX Frame filter
• DMX Protocol version
• RDM State
To save a DMX Preset List:
1) Push MENU (10) and PRESET (7) long and simultaneously to save a DMX preset list
independent from the current page shown on the display.
2) Turn and push the encoder (4) to save the DMX preset list in the desired slot.
To activate a DMX Preset List:
1) Push MENU (10) and PRESET (7) short and simultaneously to open the DMX preset list
independent from the current shown page on the display.
2) Turn and double push the encoder (4) to start a DMX preset list.
NOTICE
If Host / Client Mode was started: Loading a DMX Preset disables the host/client mode as the user
expects the new settings.
6.9 Save and Load DMX Settings
You can save the DMX preset list to an USB memory stick and upload the list to another L-Series
Plus.
To Save a DMX Preset List:
1) Connect an USB memory stick to the USB-A connector of the L-Series Plus.
2) Push MENU (10) to open the menu.
3) Turn and push the encoder (4) to open the menu USB Functions -> DMX Presets -> Save DMX
Preset.
4) Turn and push the encoder (4) to set the DMX preset list. Set Yes to confirm the setting. Set No
to cancel the procedure.
5) The DMX settings will be saved on the USB memory stick.
You can save up to ten DMX preset lists in the root directory of the USB memory stick. The file
name is <text>-DMXPres<No>.json. The L-Series Plus is looking for this string to identify a DMX
preset file on an USB memory stick. Be sure to keep the string when renaming a DMX preset file.
Otherwise the file will not be found by the device.
