5 | Other Functions
24 L-SeriesPlus User Manual
5.3 Light Preset List
The light preset list can be saved to an USB memory stick and be uploaded to another L-Series
Plus.
To Save a Light Preset List:
1) Connect an USB memory stick to the USB-A connector of the L-Series Plus.
2) Push MENU (10) to open the menu.
3) Turn and push the encoder (4) to open the menu USB Functions > Save Light Presets.
4) Set Yes and push the encoder (4) to confirm the setting. Set No to cancel the procedure.
5) The light preset list will be saved on the USB memory stick.
Up to 30 light preset lists can be stored in the root directory of the USB memory stick. The file name
is <product serial number>-Presetxx.json. The L-Series Plus is looking for Presetxx.json to identify a
light preset list on an USB memory stick. Be sure to keep the string when renaming a light preset
list. Otherwise the file will not be found by the L-Series Plus.
To Load a Light Preset List:
1) Connect an USB memory stick with one or more preset lists to the USB-A connector of the L-
Series Plus.
2) Push MENU (10) to open the menu.
3) Turn and push the encoder (4) to open the menu USB Functions > Load Presets.
4) Push the encoder (4) to open the list of the preset lists available in the root directory of the USB
memory stick.
5) Turn and push the encoder (4), to set and load a preset list. The internal preset list of the L-
Series Plus will be overwritten by the preset list.
5.4 Save and Load Settings
The device settings can be saved to an USB memory stick and be uploaded to a different L-Series
Plus. The file contains all settings except the DMX address and IP settings.
To Save the Settings:
1) Connect an USB memory stick to the USB-A connector of the L-Series Plus.
2) Push MENU (10) to open the menu.
3) Turn and push the encoder (4) to open the menu USB Functions > Save Fix. Settings.
4) Set Yes and push the encoder (4) to confirm the setting. Set No to cancel the procedure.
5) The settings will be saved on the USB memory stick.
Up to 30 settings files can be stored in the root directory of the USB memory stick. The file name is
<product serial number>-Clonexx.json. The L-Series Plus is looking for Clonexx.json to identify a
settings file on an USB memory stick. Be sure to keep the string when renaming a settings file.
Otherwise the file will not be found by the L-Series Plus.
To Load Settings:
1) Connect an USB memory stick with one or more settings files to the USB-A connector of the L-
Series Plus.
2) Push MENU (10) to open the menu.
3) Turn and push the encoder (4) to open the menu USB Functions > Load Fix. Settings.
4) Push the encoder (4) to open the list of the settings files available in the root directory of the
USB memory stick.
5) Turn the encoder (4), to select a settings file.
6) Push the encoder (4) to load the settings. The L-Series Plus restarts with the new settings after
successful upload.
