Other Functions | 5
L-SeriesPlus User Manual 23
5 Other Functions
5.1 Set the Display Behavior
You can set the intensity of the background illumination, the contrast, the behavior of the
background illumination and the orientation of the display content.
To set the display behavior:
1) Push MENU (10) to open the menu.
2) Turn and push the encoder (4) to open the menu Display Setup > [Desired Display option].
3) Set the desired behavior and push the encoder (4) to confirm the setting.
Please refer to section Device Menu for a detailed explanation of the options.
5.2 USB Functions
The L-Series Plus has an USB A port. The load capacity is 500 mA at 5V voltage. Do not overload
the USB-A port. The device accepts FAT32 formatted USB 1.0 / 2.0 memory sticks. We recommend
the use with memory sticks up to 4 GB capacity. Memory sticks with higher capacity might cause
inconvenient delays. The following USB functions are available:
• Update the firmware
• Save and load a light preset list
• Save and load a DMX preset list
• Save and load fixture settings
• Save the error and service log
You can update the firmware of the device and the remote control panel through a USB memory
stick:
To Update the Firmware:
Copy the L-Series Plus update file to the root of an USB memory stick.
1) Connect the USB memory stick to the USB-A connector of the L-Series Plus .
2) After a short time the device detects the update file on the USB memory stick.
3) Confirm the update with Yes.
4) Wait until the update is finished and the device has rebooted with the new firmware.
5) Remove the USB memory stick.
To Update a Remote Control
The Remote Control is automatically up- and downgraded by the L-Series Plus connected whenever
the firmware versions of the Remote Control and the L-Series Plus are different.
NOTICE
Disconnect all DMX cables from the device before using an USB memory stick. The data transfer
between the device and the USB memory stick might be disturbed due to interferences.
Do not remove the USB memory stick during an update or data transfer. The file system might be
corrupted. You might need to perform a recovery update to return the device to a functional state.
