Contera Bullet | Installation Manual

6. Use the supplied two Steel Straps to attach the Pole Mount Adapter to the pole and tighten the

compression screws.

7. To configure the camera, reference the camera discovery, set-up and configuration section.

CAUTION!

The captive screws must be used to properly secure the dome cover and camera housing.

Failure to use the captive fastener may result in serious injury. When mounting the dome cover to the camera

housing, ensure that the gasket is properly seated and not folded. Failure to do so may result in water and

dust ingress. Water damage from improper installation is not covered by the warranty!

Electrical Box Adapter

The electrical box adapter is used to attach the camera to a common single, double or square electrical box.

The AV-EBAS is required (sold separately).

1. Using the supplied machine screws, match the mounting holes on the electrical box adapter with the

threaded holes on the electrical box. Ensure every threaded hole is matched with a mounting hole.

2. Attach the electrical box adapter to the user supplied electrical box.

Reference #

Description

1 Steel straps with compression screws

2 AV-JBA-W junction box adapter

3 Contera Bullet camera

4 Conduit pipe

5 AV-PMA pole mount adapter

6 Apply Teflon water seal tape to the thread of ¾” NPT pipe to

avoid water leakage
