Contera Bullet | Installation Manual

6. Using the screws provided (or other hardware), attach the Corner Mount Adapter to an exterior 90

degree corner wall.

7. To configure the camera, reference the camera discovery, set-up and configuration section.

CAUTION!

The captive screws must be used to properly secure the dome cover and camera housing.

Failure to use the captive fastener may result in serious injury. When mounting the dome cover to the camera

housing, ensure that the gasket is properly seated and not folded. Failure to do so may result in water and

dust ingress. Water damage from improper installation is not covered by the warranty!

Reference #

Description

1 Attach corner mount adapter to exterior 90 corner wall

2 AV-JBA-W junction box adapter

3 Contera Bullet camera

4 Conduit pipe

5 AV-CRMA corner mount adapter

6 Apply Teflon water seal tape to the thread of ¾” NPT pipe to

avoid water leakage
