Arecont Vision ConteraIP Fisheye AV12CPD-236 Handleiding (83 Pagina's)

Handleiding

33

Snapshot

1. Click Setup > Video & Audio > Snapshot.

2. Select On, and then set resolution, most large and schedule as needed. Some

parameters are described in the table below.

Parameter

Description

Snapshot Interval

Interval between two snapshots. For example, with Snapshot Interval

set to 1 and Number of Snapshot set to 2, the camera will take 2

snapshots (take one first and then take another after 1 second).

Number to Snapshot

Currently 1, 2, and 3 snapshots are allowed.

Snapshot Mode

Schedule

: You need to set a snapshot time, e.g., 19:12:00, which

means the camera takes a snapshot at 19:12:00.

Repeat: Allows you to set an interval(unit: sec). For example,

according to the settings shown in the figure above, 60 seconds must

elapse before the camera takes another two snapshots.

3. Click Save.
