17
INSTALLATION INSTRUCTIONS
STEP 3
LIFT THE AC INTO THE WINDOW
RIGHT
LEFT
What you need:
1. Together with your helper, lift the assembled
AC into the window frame.
RIGHT
LEFT
Make sure you do this step with a helper. Very
carefully, lift the assembled AC into the window
frame. Make sure someone is holding the back
of the unit securely.
*It’s helpful to rest the unit on the inside
window sill until you’re ready to reposition
it correctly. Injury (to you and others) and
property damage can occur if not done
correctly.
2. Properly position the bottom bar BEHIND the
inside window sill.
Properly position the bottom bar behind
the inside window sill and into the bottom
horizontal channel of the window frame. The
front of the bottom bar should be pressing up
against the back edge of the sill.
*Check that air conditioner is tilted back
about 3°to 4°downward to the outside. After
proper installation, condensate should not
drain from the overow drain hole during
normal use, correct the slope otherwise.
CAUTION
If storm window blocks AC,
Please install according to the gure above.
(Continued)
