16
INSTALLATION INSTRUCTIONS
(Continued)
4. Fasten the panels to the AC.
RIGHT
LEFT
Stretch the wind screen outward and insert the
upper and lower frame strips of the Panels into
the AC card slot.
5. The AC unit is done.
RIGHT
LEFT
A
A
C C
B
A
A
Before you rush to the next installation phase,
please rst conrm the following installation is
in place:
The upper and lower frame strips of the
Panels into the AC card slot.
Top Rail on the AC with 4 Screws.
Insert the card slot on the side of the AC.
STEP 2
INSULATE YOUR WINDOW
What you need:
Cut the seal foam to the width of your window,
and stick it of the underside.
You should cut the foam to be the width of
your window from the left to the right side. Make
sure you’re cutting the foam with the adhesive, and
stick it to the underside of the window sash.
If your window already has a liner or insulationstrip,
you can skip the above step.
