19
INSTALLATION INSTRUCTIONS
THE FINAL DETAILS
RIGHT
LEFT
What you need:
1. Cut the non-adhesive insulation foam to t
the width of your window.
Make sure you are cutting the foam with the
non-adhesive sides. Measure and cut the foam
to be the width of your window from the left to
right side.
2. Use the nonadhesive foam to ll the gaps in
your window.
Stu it between the gap of the upper and lower
sashes of your window.
This will plug any air gaps and help keep out
bugs and draft.
ONE MORE THING
1. If AC is Blocked by Storm Window.
Add wood as shown in Caution illustration on page
18, or remove storm window before air conditioner
is installed. If Storm Window Frame must remain,
be sure the drain holes or slots are not caulked
or painted shut. Accumulated Rain Water or
Condensation must be allowed to drain out.
Removing AC From Window
Turn AC o, and disconnect power cord. Remove
sash seal from between windows, and unscrew
safety sash lock. Remove screws installed through
frame and frame-lock. Keeping a rm grip on air
conditioner, raise sash and carefully remove. Be
carefully not to spill any remaining water while lifting
unit from window. Store parts with air conditioner.
2. Normal Sounds
High Pitched Chatter
High eciency compressors may have a high
pitched chatter during the cooling cycle.
Sound of Rushing Air
At the front of the unit, you may hear the sound
of rushing air being moved by the fan.
Gurgle/Hiss
“Gurgling or hissing”noise may be heard due to
refrigerant passing through evaporator during
normal operation.
Vibration
Unit may vibrate and make noise because of
poor wall or window construction or incorrect
installation.
Pinging or Switching
Droplets of water hitting condenser during normal
operation may cause “pinging or swishing” sounds.
This noise can be reduce by removing the water plug
at the bottom of unit’s rear as shown below. Removing
this plug will lower the Energy Eciency of your unit.
NOTE:
Don’t try to drill any holes on the
base pan to eliminate the normal sounds,
otherwise it will void the warranty. Internal
parts can be permanently damaged by drilling
a hole into the base pan or any other location
on the machine. The machine is designed to
evaporate the water under normal conditions,
not continuously drain.
(Continued)
