Valve Body Assembly and Parts List

Item No. Quantity Part No. Description

1 3 A-12112 Screw

2 1 A-13546 End Plug Retainer

3 1 A-13363 Washer

4 1 A-13296 Screw

5, 6, 7, 8 1 A-60102-20 Piston Softener & Filter

9, 10 1 A-60125 Seals (5) & Spacers (4) Assy.

11 1 A-61400-34 Valve Body Assembly, 3/4" Dist.

12 4 A-13305 O-ring, Adapter Coupling

13 2 A-19228 Adapter Coupling

14, 15 2 A-13255-FT Kit Adaptor Clip

16 1 A-187706 Yoke, Plastic, 1"

1 A-187706-02 Yoke, Plastic, 3/4"

17 1 A-13304 O-ring, Distributor Riser Tube

18 1 A-12281 O-ring, Top of Tank

19 1 A-56247 Drain, Quick Connector, Elbow, 1/2" Tubing

20 1 A-01019 O-ring, DLFC

21* 1 A-120XX DLFC Button

22 1 A-50011 Locking Clip, Drain QC

23 1 A-13245 BLFC Button Retainer

24** 1 A-120XX BLFC Button

25, 26, 27 1 A-13244 Brine Line Quick Connector 3/8" Tubing

28 2 A-13315 Screw

29 1 A-13166 Injector Cover

30 1 A-13303 O-ring, Injector Cover

31 1 A-01002 O-ring, Injector (Included w/ Injector)

32*** 1 A-10225-X-N Injector

33 1 A-01017 O-ring, Injector (Included w/ Injector)

34 1 A-56226 Screen, Injector

35 1 A-13163 Injector Body

36 2 A-13301 O-ring

37 1 A-13497 Air Disperser

38 1 A-12638 O-ring

39 - 45 1 A-60032 Brine Valve Assy

46 1 A-13918 BLFC Plug

47 1 A10913BLK-02 Injector Black Capped

48 1 A-13857 Brine Valve Plug
