AQUASURE HARMONY SERIES

SYSTEM TROUBLESHOOTING

Use your phone to scan the QR code below or visit https://aquasureusa.com/support for most up

to date system troubleshoot. You can also contact our support team at support@aquasureusa.com.

Flow Rate @ 50 psi (3.5 bar) Valve Alone:

Continuous 15 psi (1 bar) Drop: 20 gpm (76 lpm)

Peak 25 psi (1.7 bar) Drop: 26 gpm (98 lpm)

Max Backwash 25 psi (1.7bar) Drop: 7 gpm (26 lpm)

CV 1 psi (0.07 bar) Drop: 5.0

Regeneration/Backwash:

Downow/Upow: Downow Cycles: 5

Adjustable Cycles: All

Time Available: Up to 999 minutes per cycle

Meter:

Accuracy Range:

Turbine Paddle 0.25 - 15 gpm

(0.95 - 57 lpm) ± 5%

Capacity Range: 1 - 9,999,999 gal

Valve Specifications:

Inlet/Outlet: 1" or 3/4", NPT

Mounting Base: 2-1/2" 8 NPSM

Distributor Pilot: 1.05" OD

Drain Line: 1/2" Quick Connect Elbow

Brine Line: 3/8" Quick Connect

Height: 7" (178 mm)

Weight

(Valve Gross): 4.84 lb (2.1 kg)

Additional Information:

Electrical Rating: Input: 120V AC 60Hz, Output: 24 V DC

Max. VA 3 VA

Water Pressure:

Hydrostatic: 300 psi (21 bar)

Working: 20 - 125 psi (1.4 bar - 8.6 bar)

Temperature: 34 - 110 °F (1 - 43 °C)
