User's Manual
3. POSSIBLE SETUPS
The device can be used in three different setups, shown below:
SETUP
flexiverter+AUX card Double-flexiverter flexiverter+multiverter
How it works Converts between built-in
interface and the AUX card,
or splits AES50 to the AUX
card.
For a list of AUX cards, see
3.1 Available AUX cards .
Devices are connected via
FlexLink cable.
Converts between one
FLX(+AUX) and the other
FLX(+AUX).
Flexiverter connected to
multiverter via FlexLink
cable.
FLX(+AUX) serves as
extension to the MVR-64
Channels
(all can be used at
the same time)
64x64 Dante @ 48kHz
32x32 Dante @ 96kHz
16x16 Dante @ 192kHz
or maximum capacity of the
AUX card, whichever is less
64x64 Dante @ 48kHz
32x32 Dante @ 96kHz
16x16 Dante @ 192kHz
plus what the AUX card
provides
448x448 from multiverter
plus 64x64 Dante
plus what the AUX card
provides
Redundant
power supply
up to 2x up to 3x up to 3x
Battery-powered
operation
(DC 12-15V)
yes yes yes
Sample Rate
Conversion
no no yes (with SRC-64 card in
Multiverter)
Signal splitting yes (to AUX or FlexLink) yes (to AUX or FlexLink) yes, to everything
Channel-wise
routing
no no yes, via MVR-64 (web, telnet
or serial terminal)
Remote control no no yes, via MVR-64 (web, telnet
or serial terminal)
Rack mount 1U total 1U total 2U total
3.1. Available AUX cards
At the time of writing (2021-11), the following AUX cards are available. More will
come, please check www.appsys.ch for updates.
Item Description
AUX-ADAT 16x16ch ADAT I/O (2x Toslink In+2x out). Supports also S/PDIF
AUX-AES3 8x8ch AES3 I/O on 1x DB25, fully transformer isolated
AUX-AES67 64x64ch AES67 network card
6
