Technical Data ACRC300 Series, ACRC600 Series
Optional features
Cable water detector A leak detection cable for 300-mm units (NBES0308 and NBES0309) or 600-mm units (AP9325 and AP9326) is
placed on the floor or sub-floor around all possible leak sources. If water or other conductive liquids contact the
cable anywhere along its length, the microprocessor controller visually and audibly announces a leak. The 6.1-m
(20-ft) cable may be cascaded to make custom lengths up to 24.4 m (80 ft).
Network cable Various lengths of network cable are available to ship with your cooling system. The network cable is used to
interconnect multiple cooling units in a redundant group, as well as to connect the network management card to
your local area network (LAN).
Power trough Overhead power distribution between adjacent NetShelter racks allows for removal of the InRow RC unit without
disrupting overhead power cabling.
Data partition Overhead cable distribution between adjacent NetShelter racks allows for removal of the InRow RC unit without
disrupting overhead cabling.
Height adapters To match the height of the InRow RC unit to various rack heights, height adapters are available for NetShelter 42-
U VX, 45-U SX, and 48-U SX racks.
Depth extender Used to match the depth of the InRow RC unit to deeper racks.
Rack Air Containment The Containment Solution isolates the airflow of individual racks and InRow cooling units from the whole IT
environment, increasing efficiency while allowing for high density deployment.
Aisle Containment The Containment Solution isolates pods (two rows of racks sharing a common aisle) from the whole IT
environment, increasing cooling efficiency at any density. For details, see EcoAisle™ aisle containment system.
Upper piping kit Available for top-piping configurations and can be field installed.
NOTE: Pre-installed in ACRC600 series units.
Dew point control
pump (DPCP)
(ACRC301H only)
The DPCP provides a second layer of protection in case the IT room humidity control system or humidity barrier
fails. It allows the unit to operate 100% condensate-free (unlike traditional forms of condensation removal that
requires condensate removal piping) by stopping condensation before it can form. The DPCP works by
recirculating coil water to keep the unit operating above the dew point at all times.
Disposable pleated
filter
(ACRC300 series
only)
The filtration of conditioned air is extremely vital to maintaining the clean, particle-free environment required by
electrical equipment. As an optional feature, the system uses a 50.8-mm (2-in) pleated, deep-loading, 30%
ASHRAE 52.1 filter (MERV 8 per ASHRAE 52.2).
85% ASHRAE 52.1
filter
(ACRC600 series
only)
Electrical equipment requires clean, particle free air, thus making the filtration of the air extremely important.
Optionally, the system uses an 85% efficient, 102-mm (4-in.), deep loading, pleated filter. Deeper filters produce a
lower pressure drop, requiring less energy during normal operation. The 100% synthetic media will not absorb
moisture and is resistant to most common chemicals. The filter is moisture resistant up to a 100% relative
humidity. Filters are easily replaceable from the rear of the unit. (MERV 13 per ASHRAE 52.2, EN779 F7).
Seismic latch kit Users must obtain and install the seismic latch kit for locations that require seismic certification.
Control type
The controller utilizes proportional/integral/derivative (PID) settings, a time-proven
precision environmental control method. This allows for custom tuning of control
variables to achieve optimal system response.
990-5792B-001 21
