Discrete 4 Pro Synergy Core User Manual

Page 44

MIXERS

This tab allows you to access the four 32-channel virtual mixers.

Use the Input Selectors to assign an audio input to each channel.

Each mixer is completely independent. You can have different inputs for each mixer.

Each channel strip has the following components:

• Panning knob with values between –30 (hard left) and 30 (hard right),

• Volume fader which allows you to adjust the volume of the signal

• Peak meter which shows you the real time signal in dB in a range from –60 to

0dB.

• Solo button which allows you to mute the rest of the channels in the mixer and

listen to only the Soloed one.

• Mute button which allows you to Mute the selected channel.

• Link button (1 available per pair) allows you to link all the controls with the

neighbor channel strip and adjust the settings on both channels together. This is

mostly used when you have a stereo signal using two channels for left and right.

Default and Compact view – 8/32 channels

On the top right side of the mixer, you can find a switch between 8 and 32 channels

which changes the view of the mixer. In the 8-channel mode, the mixer fits 8 enlarged

channel strips. In the 32-channel mode all 32 channels are visible simultaneously.

Scroll bar

Just below the channel strips you can find a scroll bar which allows you to scroll between

all 32 available channels in the mixer without using the extended view. This scroll is

available in the 8-channel mode view only.
