10
13.1 Breaker Reset (2 in 1 Power Switch)
The 2 in 1 power switch combines power and breaker function.
Please follow below steps to reset the breaker;
Step 1: Please power switch to the OFF position;
Step 2: Wait 60 seconds;
Step 3: Flip the switch back on.
**If the breaker (switch) still jumps off after reset, please contact
your local Antari dealer for assistance.
Breaker Specification
250V 20A
14. Technical Specifications
F-8
Input Voltage
EU Model: AC 220-240V, 50/60Hz 14.5A
Rated Power
3500W
Warming-up Time
9 minutes (approx.)
Fluid Consumption
200 ml/min (100% output)
Fluid Tank Capacity
20 Liters (5.28 Gallon) x 2
Compatible Fluid
FLG、FLH、FLR、FLZ
Ambient Temp. Range
0°C – 40°C (32°F – 104°F)
Control Methods
Manual、Timer、DMX512、Wireless (Optional)、W-DMX (Optional)
Interface
XLR 3-Pin and 5-Pin Connector (DMX)、Neutrik powerCON TRUE1 Connector (Power)
DMX Channels
2 Channel
Included Accessories
N/A
Optional Accessories
EasySwtich Wireless Remote、EasySwitch W-DMX
Dimension
L 804 W 677 H 976 mm (L 31.66 W 26.66 H 38.43 inch)
Weight
100.0 kg (220.46 lbs.)
15. Warranty Disclaimer
We guarantee the merchandise manufactured by us to be free from defect in material and workmanship for a period
of one year. Our obligation and liability under this warranty shall be restricted to repair or replacement at our
factory or local authorized dealer. We assume no liability of the products that are improperly used or used for any
purpose other than that for which they are specially designed. This warranty shall not apply to any merchandise
which has been repaired, altered or assembled outside our factory in any way so as in our judgment to affect its
performance, nor which has been subjected to misuse, negligence, or accident nor to any merchandise operated
contrary to our printed instructions. We will not allow or be liable of any loss or any damages of any kind in
connection with the use, sale, or repair of any merchandise purchased from us.
