In case you need additional spare parts, please contact your local reseller or our service team at:angenieuxservice@fr.thalesgroup.com.

Spare part

Optimo Ultra Compact

Standard

Optimo Ultra Compact

Wide Angle

(1) - Front cap

0311819

(2) - Front element

66070757AA

66070756AA

(3) – Front cover

66068379AA

(4) - Front brand ring

66069059AA

66069664AA

(5) - Engraved focus ring

Feet: 66070583AA

Meter: 66070581AA

(6) - Focus gear ring

66066724AA

(7) - Lens support / (8) - LEMO connector

66070258AA/ 0315740

(9) - Focus ring screws (x3)

0990297

(10) - Middle brand ring

66069060AA

(11) - Rear cap

0311816

(12) - Connector for metadata

66071762AA

(13) - Rear Filter

66066659AB

(14) - PL mount

66066785AB

66069672AB

(15) - Iris gear ring + iris core (paired) and p11-x3 cam followers

66070858AA + 3x 66066717AA

(gestion service?)

66070858AA + 3x 66066717AA

(gestion service?)

(16) - Engraved zoom gear ring

66066723BA

66066723CA

(17) - Deco red ring

66066352AA

(18) - Zoom & iris index ring

66066722AA

Flange shim set of 9 shims (see size detail in section 6)

0321060

Screws for lens support including LEMO connector holder (x2 with thread lock)

0982467

Screws for camera interface metadata connector (x2)

0913327

Screw for middle brand ring (x1)

0984957

Screws for front brand ring (x3)

0982397

Screw for zoom and iris index ring (x3)

0984957

Screws for engraved focus ring (x3)

0990297

ADDITIONAL ACCESSORIES COMPATIBLE

Lemo to USB cable for calibration must have its own power supply channel

Electronic setting software to be downloaded

https://www.angenieux.com/service-and-support/
