• Using a hexagonal wrench (1.5mm), unscrew the 6 screws of the optical
unit (5) and gently remove it (6) using the rear protective cap of the
optical unit and taking care not to hurt it on the mechanics of the lens
nor on the work table.
• Using a Phillips screwdriver, unscrew the 6 screws from the iris ring (7)
and remove it from the back of the lens (8).
• Now slide the corresponding engraved iris ring to the optical unit to
be installed and screw it onto the lens body with the previous 6 screws.
Check its position by turning the ring gently from stop to stop.
• Carefully position the new rear optical unit with the index pin. Reassemble
the 6 hexagon screws.
• Reassemble the red ring
• Reassemble the rear mount
• Slide the rubber of the focal ring onto the front of the lens (9) to release
the three retaining screws of the ring
• Unscrew the three screws (10) and slide the ring up or down to display
the corresponding focal length engravings at the rear group (11)
• Screw the focus ring back in place and return the rubber to the focal
ring.
Procedure for EZ3 (FIGURE 7) :
• Place the rear FF next to the EZ3 and remove the rear protective cap (1)
• Unscrew the red retainer(2)
• Remove the rear S35 from the EZ3 (3) and put the rear FF
• Unscrew the x4 iris witness mark ring maintaining screws (4)
• Rotate the iris mark ring at 180° (5), in order to reveal the FF engraving
• Screw the x4 iris witness mark ring maintaining screws (4)
• Remove the zoom rubber ring (6)
• Unscrew the p24-x3 zoom witness mark ring maintaining scews (7)
• Drag the zoom witness mark ring (8) in order to reveal the FF engraving
• Screw the p24-x3 zoom witness mark ring maintaining screws (7)
• Put the zoom rubber ring (6)
• Put the rear protective cap on the rear S35
Video link :
