4
AJ400 GDI
Injector Cleaner & Tester
ANCEL
-
>2
Pulse width
-
>3
Time
-
>4
No. / Mode
F->3
Leakage test
F->4
Injecting flow test
F->5
Working m
ode
s
test
-
>1
Mode 1 (Acceleration test)
-
>2
Mode 2 (Deceleration test)
-
>3
Mode 3 (Acceleration+ Deceleration test)
F->6
On
-
Vehicle cleaning
Fuel pressure + / -
Resistance test
Backlight on / off
Setting
bp. 0-8: Buzzer sound level
dl. 1-7: Display brightness
bl. 0-15: Backlight brightness
sa.0/1: 0-Not save as default. 1- Save as default
Run / Stop
III. Installation
3.1 Installation of GDI and top-supply injectors
(
EFI/MPI/SFI
)
1) Choose the adapters according to the fuel top-supply injector from the coupler box and mount a proper O-ring
on it. Remember to apply a little lubricating fuel on the O-ring.
2) The adapters for fuel top-supply injector are 4 types:
Thread sealing type: here are with coarse thread and fine thread.
O-ring sealing type: here are with big hole and small hole.
3) If the injectors cannot be fixed because of the hole being bigger than the injector, need to sue the auxiliary support.
4) Need to adjust the relative position between the Knurled nut and adjustable screw so that the injectors can be fixed well
on the unit.
(Installation of EFI/MPI/SFI/GDI injectors)
