Chapter 3: Windowing Processor Configuration Options
23
N1512 Windowing Processor User Manual
Network Setup Section
The Network Setup section of the Unit Settings page is shown in Figure 14. Options are described in Table 6. In the Network
Setup section on the Unit Settings page:
• IP address is required, and will be used as the control IP address.
•Configure the Netmask and default Ga t e w a y address as needed or directed by IT personnel.
NOTE: If you do need to make changes to the Network Setup section, click Trial Save once changes are made. If the control IP address
is different from the default, you will need to log in to the unit using its new IP address. Once re-logged back in, click Conf irm to keep
the changes. If the unit is power cycled before the changes are confirmed, it will revert to its original IP address.
FIG. 14
Network Setup Section
TABLE 5 Unit Settings Page: Stored Presets Section
Option Description Notes
Stored Presets field Lists presets already stored in this device.
Sort button Click to rearrange and re-index the Stored Presets in
any order.
Delete button Click to delete the selected stored preset.
Export button Click to export the selected stored preset to later
import to another Windowing Processor.
Choose File button Choose a stored preset file to import to this Windowing
Processor.
Import button Click to import the preset file chosen using the Choose
File button.
Append Import
checkbox
Enable this checkbox if you want to append the current
stored presets with the imported presets.
If this option is not enabled, the import will overwrite
the currently stored presets.
TABLE 6 Unit Settings Page: Network Setup Section
Option Description Notes
IP Mode Configure the IP address mode. When set to AUTO IP,
an IP Address in the range of 169.254.xxx.xxx with
Netmask of 255.255.0.0 and Ga t e w a y address of
169.254.1.1 will be automatically assigned to the
N1512 Windowing Processor by the control software.
When set to DHCP, an IP Address in the range of the
DHCP server on the network will be automatically
assigned to the N1512 Windowing Processor. When set
to STATIC, an IP address, Netmask, and Ga t e w a y
address must be manually entered.
DHCP is the default setting. However, using DHCP
beyond initial setup is generally not recommended. If
the device is set to DHCP and fails to receive an
address from the DHCP server in time, it will revert
back to the AUTO IP Address (169.254.xxx.xxx) until
the unit is rebooted.
IP address View the current IP address of the N1512 Windowing
Processor. When in STATIC mode, you may enter a new
IP address into this field.
Netmask View the current Netmask of the N1512 Windowing
Processor. When in STATIC mode, you may enter a new
Netmask into this field.
Gat e w a y a dd re s s View the current Gat e w a y a dd r e s s of the N1512
Windowing Processor. When in STATIC mode, you may
enter a new Gat e w a y add r es s into this field.
Trial Sa ve Click to initially save IP address changes. Once you log
in to the unit using the new address, you will be able to
confirm and accept the changes permanently.
