Encoder Configuration Options
N2312/N2322 User Manual
29
Status Section
The Status section of the Settings page is shown in Figure 22. Options are described in Table 4.
FIG. 22 Status Section
TABLE 4 Settings Page: Status Section
Option
Description
Notes
HDMI Status
Indicates if a video source is connected to the Encoder.
Input Resolution
Indicates the video resolution of the currently
connected source.
Port 50001 Source IP
Shows the IP address of the currently connected device
or displays Disconnected if no connection exists.
Port 50001 can only accept a single external
connection at a time. If a device is currently showing
the port occupied (by a control system or other
device), then other connections will be rejected.
However, connection attempts from the same IP will
override the current connection.
Port 50002 Source IP
Shows the IP address of the currently connected device
or displays Disconnected if no connection exists.
Port 50002 can only accept a single external
connection at a time. If a device is currently showing
the port occupied (by a control system or other
device), then other connections will be rejected.
However, connection attempts from the same IP will
override the current connection.
Serial Source IP
Shows the IP address of the currently connected device
or displays Disconnected if no connection exists.
Only a single external connection can be accepted on
the port. If a device is currently showing the port
occupied (by a control system or other device), then
other connections will be rejected. However,
connection attempts from the same IP will override
the current connection.
Port P0 Status
Shows the IP address of the currently connected device
or displays Disconnected if no connection exists.
Port P1 Status
Shows the IP address of the currently connected device
or displays Disconnected if no connection exists.
