20
SYSTEM MENU
ADJ VIZI BEAM 12RX - SYSTEM MENU
Default setting shown in bold
Supports Software Versions: 2.6
MAIN MENU OPTIONS / VALUES (Default Settings in BOLD) DESCRIPTION
DMX Settings
DMX Address 001 - 512
Shall be used to set the units starting DMX address
channel. Depending on set DMX mode, unit shall not
allow to be addressed any higher that will not allow for
all channels to be accessed from the console.
DMX CH Mode 13ch, 17ch Shall be used to set the units desired DMX mode.
No DMX Status
Hold Last
Shall be used to set the units behavior when DMX
signal is not present. Hold shall be the default setting
and unit shall hold all last channel values received
from the console when signal is lost.
Blackout
Blackout option shall take all channels to zero (0)
when signal is lost.
Manual
Manual Settings option shall take all channels to the
last set Manual channel settings when signal is lost.
Personality
Status Settings
Pan Invert ON / OFF
Tilt Invert ON / OFF
P./T. Feedback ON / OFF
Pan Degree 540
P./T. Speed
Speed 1, Speed 2, Speed
3
Hibernation OFF, 01M~99M, 15M
When DMX signal is not present for the set time, the
unit shall go into standby mode after the set time.
When set to OFF, unit shall never go into hibernation
mode. The unit should have 01M to 99M options… so
01M, 02M, 03M… 99M (M=Minutes). 15M should be
default.
Reset Motors
Reset All Motors YES / NO
Pan/Tilt Reset YES / NO
Color Reset YES / NO
Gobo Reset YES / NO
Prism R/P Reset YES / NO
Shutter Reset YES / NO
Focus Reset YES / NO
Frost Reset YES / NO
Display
Intensity 1-10
Display Invert ON / OFF
Screen Saver Delay OFF - 10 minutes
Display Lock On/Off ON / OFF
Service
(Passcode = 050)
Calibration
Pan 128-127
Effects adjustments. Do not adjust effect settings when
performing a factory reset at the same time.
Tilt 128-127
Shutter 0-255
Color -128~127
…
Focus -128~127
High Temp Fan Mode ON / OFF
Unit runs fan continuously to keep lamp temp within a
safe range
USB Port Power ON / OFF
Update Software
Factory Restore YES / NO Reset to factory default
