17
GOBOS
GOBO HOLDER DIM DRAWING
A
A
BB
Ø16.5mm
+0.1
0
A-A
B-B
Gear Module: M = 0.8
Tooth Number: Z = 28
Orientation
made to
concave point
ø 29mm (1.14in)
39mm (1.54in)
5.9mm
(0.23in)
ø 16.6mm
(0.65in)
1.8mm
(0.07in)
0.5mm
(0.02in)
1.0mm
(0.04in)
ø 14.5mm
(0.57in)
(0.6496in
+0.0004
0
)
Gobo installation
surface should be
at
3.0mm
(0.12in)
4.0mm
(0.16in)
ø 26.0mm
(1.02in)
ø 27.2mm
(1.07in)
6.3 + 0.1mm
(0.248 + 0.004in)
Ensure that gobo ring,
gobo, and retainer are
securely installed before
inserting gobo holder
back onto gobo wheel.
