for a channel. Never use the gain control to adjust a channels output volume. Setting the gain level
properly will ensure a clean output signal. An improper gain level adjustment will send a distorted
signal throughout the entire audio line which may damage speakers and amplifiers. To properly set a
channels gain level control:
1. Be sure the Master VoluMe Control (14) is set to level 8.
2. Set the Channel fader (23) to level 8.
3. Begin playback on an audio source connected to the channel you are adjusting.
4. Use the Gain Control to adjust an average output volume of +4 dB.
5. Repeat this step for all channels.
4. source seLector knoB - These knobs are used to select the input source assigned to each
channel. Each channel may only be assigned one input source at a time. This knob must be in the
“phono” position for turntable operation.
5. channeL voLuMe LeveL indicators - The LED indicators that run along each channels EQ
section are used to measure incoming signal levels. Use these indicator to visually maintain an average
signal output of +4dB. A consistent average output level of +4dB will produce a clean output signal.
6. channeL treBLe controL - This knob is used to adjust the treble levels of a channel
allowing for a maximum treble gain of 12dB or maximum decrease of -∞dB. Turning the knob in
a counter-clockwise direction will decrease the amount of treble applied to a channel signal, turn-
ing the knob in a clockwise direction will increase the amount of treble applied to a channel signal.
channeL MidranGe controL - This knob is used to adjust the midrange levels of a channel
allowing for a maximum midrange gain of 12dB or maximum decrease of -∞dB. Turning the knob in a
counter-clockwise direction will decrease the amount of midrange applied to a channel signal, turning
the knob in a clockwise direction will increase the amount of midrange applied to a channel signal.
channeL Bass controL - This knob is used to adjust the low frequency levels of a channel
allowing for a maximum bass gain of 12dB or maximum signal decrease of -∞dB. Turning the knob in
a counter-clockwise direction will decrease the amount of bass applied to a channel signal, turning the
knob in a clockwise direction will increase the amount of bass applied to a channel signal.
7. auX 4 input - Only CD players, Tape Decks and other line level instruments may be connected
to these jacks. Never connect a turntable to these input jacks, this May seriously daMage
your Mixer! The red colored RCA jack represents the right channel input and the white represents
the left channel input. Input volume will be controlled by the channel four fader.
8. Main poWer sWitch - This is the main power ON/OFF button. Before main power is applied,
be sure you have made all connections to the mixer. Also be sure your amplier(s) is(are) tuned off.
Remember to avoid damaging pops to the speakers, the mixer is turned on rst and turned off last.
9. Master output BaLance controL - This knob is used to control the pan, adjust how much
of the signal is sent to the left and right output level. For true stereo imaging, maintain the knob in the
12 o’ clock position.
10. Master voLuMe LeveL indicators - The dual MASTER LEVEL LED indicators are used
to detail the master fader output level. The meters will detail the output level of both the left and right
channels.
11. Booth channeL assiGn knoB - This knob is used to select the channel that you want the
booth signal to be directed to. Connect your monitor system to the Booth XLR sockets located on the
rear panel.
MX-1400 CONTROLS aNd FUNCTiONS cont.
©American Audio® - www.americanaudio.us - MX-1400 Instruction Manual Page 9
