©American Audio® - www.americanaudio.us - MX-1400 Instruction Manual Page 10
Booth treBLe - This knob is used to adjust the treble level of the booth signal. Turning the
knob in a counter-clockwise direction will decrease the amount of treble applied, turning the knob in
a clockwise direction will increase the amount of treble applied.
Booth Bass - This knob is used to adjust the bass level of the booth signal. Turning the knob in a
counter-clockwise direction will decrease the amount of bass applied, turning the knob in a clockwise
direction will increase the amount of bass applied.
Booth LeveL - This knob is used to adjusts the monitor volume output level. Turn the knob in a
clockwise direction to increase the monitor volume.
12. cue seLector Button - These buttons are used to activate a channels “CUE” mode. The
red CUE LED will glow when a channels cue mode is activated. The Cue function sends a channels
incoming signal to the headphones. The cue level is adjusted by the Cue leVel Knob (18). Be sure
the Cue Mixing Knob (20) is set to the “CUE” position to hear a selected channel source.
13. Master output Mono/stereo sWitch - This switches the Master Output signal between
stereo and mono.
14. Master voLuMe controL - This slider is used to control the master output level (main
volume). To avoid distorted output try to maintain an average output signal level no greater than +4
dB. (see Channel Gain 2) To avoid speaker damage that may be caused by excessive volume, be sure
this slider is always set to zero (completely down) before turning the unit on.
15. Q-start on/oFF sWitch - This function works in conjunction with a compatible American DJ®
or American Audio® “Q” Start CD player. When used with a compatible CD player, you can use the
crossfader to start and stop a CD Player with the slide of the mixer’s Crossfader (16). The ON/OFF
“Q" START SWITCH activates the FADER “Q" START feature. When in the ON position, the FADER
“Q" START automatically returns the CD player to the preset CUE POINT.
For example; Assuming you have two compatible American Audio™ CD players or a
compatible dual CD player connected to channels one and two. When the Fader "Q" Start option
is turned on, sliding the crossfader to the far left position will trigger playback on CD player
1. When the crossfader is pushed to the far right position, playback on CD player 2 will
begin, and CD player 1 will return to the cue position. Refer to your American Audio CD
player user manual for setting CUE POINTS. Turn the ON/OFF SWITCH to the OFF
position to disengaged “Q” Start function and resume to a normal fader.
16. Feather Fader pLus crossFader - This fader is used to blend the output signals of chan-
nels one and two together. When the fader is in the full left position (channel 1), the output signal of
channel one will be controlled by the master volume level. The same fundamentals will apply for chan-
nel two. Sliding the fader from one position to another will vary the output signals of channels one
and two respectively. When the crossfader is set in the center position, the output signals of both the
channels one and channels two will be even.
17. crossFader curve adJustMent - This rotary knob is used to change the way the cross-
fader will operate. The crossfader can operate in different modes, “NORMAL CURVE”, “QUICK CURVE”
or any variation of the two. (Quick Curve usually used for scratching).
18. cue LeveL voLuMe controL - This knob is used to adjusts the headphone volume output
level. Turn the knob in a clockwise direction to increase the headphone volume.
19. spLit cue - This button will activate the "Split Cue" function. When used with a set of stereo
headphones, the Split Cue function will assign the Cue signal to the left channel of the headphones
MX-1400 CONTROLS aNd FUNCTiONS cont.
