sents the left channels output.
34. DRIVE 1 DIGITAL OUT - This jack sends a
digital stereo out signal. Use this connection to
create near perfect copies of your disc to a Mini
disc, CD-R, or any other recording device with a
digital input.
35. DRIVE 1 REMOTE JACK - Connect the sup-
plied 8 pin din cable from this jack to the remote
control's channel 1 remote connector. This will
allow you to control the player functions with the
remote unit.
36. VOLTAGE SELECTOR -
Because power
supplies vary from location to location a voltage
selector switch has been incorporated in the unit's
design. This switch can select a voltage input of
120v or 220v to accommodate the two major
power source. Always be sure to disconnect the
power plug before changing the voltage.
*Only dual voltage models have this swit
ch.
37. POWER CONNECTOR - This is the main
GENERAL FUNCTIONS AND CONTROLS (Cont.)
©American Audio® - www.americanaudio.us - MCD-810™ Instruction Manual Page 13
power connection. Only use the supplied polar-
ized power cord. Use of any other power may
result in sever damage to the unit. Be sure the
local power matches the unit’s required power.
38. DRIVE 2 AUDIO OUT R & L - These jacks
send a left and right analog mono output signal.
Use these jacks to send standard audio to a
mixer or receiver. The red colored jack represents
the right channel output and white jack repre
-
sents the left channels output.
39. DRIVE 2 DIGITAL OUT - This jack sends a
digital stereo out signal. Use this connection to
create near perfect copies of your disc to a Mini
disc, CD-R, or any other recording device with a
digital input.
40. DRIVE 2 REMOTE JACK - Connect the sup-
plied 8 pin din cable from this jack to the remote
control's channel 2 remote connector. This will
allow you to control the player functions with the
remote unit.
