INPUT CHANNEL EQ:
HiGH: 12kHz Shelving
Mid: 2.5kHz Peeking
LOW: 80Hz Shelving
TURNOvER/ROLL OFF FREQUENCiES: Located 3dB Below Maximum Boost/Cut
GAIN CONTROL (mONO/STEREO COmBINATION INPUT CHANNEL): 40dB Variable (-20db ~ +20dB)
GAIN CONTROL (mONO INPUT CHANNEL): 44dB Variable (-50dB ~ +6dB), (-30dB ~ +14dB)
CROSSTALK (at 1kHz): -70dB Between Input Channels,
-70dB Between Input/Output Channels
©American Audio® - www.americanaudio.us - M1224FX Instruction Manual Page 25
M1224FX SPECiFiCaTiONS
-INPUT
Input Connector
Input
Impedance
Nominal
Impedance
Rated
Input Level
Connector Type
CH Mic 4kΩ 50 ~ 600Ω -50dB XLR 3-31 Type Balanced
CH Line 10kΩ 600Ω -30dB
Phone Jack (TRS) T = Hot
R = Cold S = GND
Stereo Input Mic 3kΩ 600Ω -44dB XLR 3-31 Type Balanced
Stereo Input 5kΩ 600Ω -20dB Unbalanced Phone Jack
Mono Channel Insert Input 10kΩ 600Ω 0dB
Phone Jack (TRS) T = Out
R = In S = GND
Tape In 10kΩ 600Ω -10dBV RCA pin Jack
-OUTPUT
Output Connector
Output
Impedance
Nominal
Impedance
Rated Output
Level
Connector type
MIX Out L/R 240Ω 20KΩ +4dB Balanced Phone Jack
ALT 3/4 75Ω 10KΩ +4dB Unbalanced Phone Jack
CTRL Room Out 75Ω 10KΩ +4dB Unbalanced Phone Jack
Aux Send 75Ω 600Ω +4dB Unbalanced Phone Jack
Mono Channel Insert Input 600Ω 10kΩ 0dB
Phone Jack (TRS)T = Out
R = In S = GND
Rec Out 600Ω 10kΩ -10dBV RCA pin Jack
Phones Out 100Ω 33Ω 3mW Stereo Phone Jack
