©American Audio® - www.americanaudio.us - M1224FX Instruction Manual Page 24
Model: M1224FX
POWER SUPPLY: AC 115v~60Hz/230v~50Hz
Single Voltage:
AC 100V, 50/60Hz (Japan); AC 110V, 60Hz (Colombia)
AC 120V, 60Hz (U.S.A. and Canada); AC 127V, 60Hz (Mexico)
AC 220V, 50Hz (Chile and Argentina); AC 240V, 50Hz (Australia)
AC 220V, 60Hz (Philippines and Korea)
AC 230V, 50Hz (Europe, U.K., New Zealand, South Africa, and Singapore)
DIMENSIONS: 420mm (W) x 328mm (D) x 90mm (H)
16.5” (W) x 12.9” (D) x 3.54” (H)
WEIGHT: 7.49 Lbs. / 3.4 Kgs.
POWER CONSUMPTION: 36W
OPERATING TEMPERATURE: 5 to 35 deg. C; Humidity: 25 to 85% RH
(non-condensing); Storage Temperature: -20 to 60 deg. C
MAXIMUM OUTPUT LEVEL (0.5% T.H.D. AT 1kHz): +26dB (Main L/R), +20dB (ALT 3/4, Aux/EFX, & Control Room)
+20dB (Insert), More than 100mW (Headphones) @ 33Ω
FREQUENCY RESPONSE: 20Hz ~ 20kHz, +1/-2dB (Mix L/R, ALT 3/4, Aux/EFX Send, &
Control Room)
T.H.D. (Total Harmonic Distortion): <0.1% @ +14dB 20Hz ~ 20kHz (Mix L/R, ALT 3/4, Aux/EFX
Send, & Control Room)
MAXIMUM VOLTAGE GAIN:
MIC IN to MAIN L/R: 74dB
MIC IN to ALT 3/4: 74dB
MIC IN to AUX (PRE): 66dB
MIC IN to AUX (POST): 76dB
MIC IN to EFX (REV): 76dB
MIC IN to CONTROL ROOM L/R: 80dB
MIC IN to REC L/R: 52.2dB
LINE IN to MAIN L/R: 54dB
LINE IN to ALT 3/4: 54dB
LINE IN to AUX (PRE): 46dB
LINE IN to AUX (POST): 56dB
LINE IN to EFX (REV): 56dB
LINE IN to CONTROL ROOM L/R: 60dB
STEREO IN to MAIN L/R: 44dB
STEREO IN to ALT 3/4: 44dB
AUX RETURN IN to MAIN L/R: 16dB
TAPE IN to MAIN L/R: 20dB
HUM AND NOISE [(AVERAGE RS = 150Ω) (Master Fader At Nominal Level & All Channel Faders At Minimum)]:
MIX L/R, ALT 3/4, AUX/EFX SEND, CONTROL ROOM OUT: -127dB Equivalent Input Noise, -95dB Residual Noise
MIX L/R, ALT 3/4, AUX/EFX SEND, CONTROL ROOM OUT: -88dB
CHANNEL INDICATORS:
PEAK: An indicator for each channel turns on when the pre-channel fader signal is 5dB below clipping.
INTERNAL DIGITAL EFFECT: 100 Selectable Presets/Foot Switch Controlable
LED METERS: 10-Segment LEDx2, Main L/R, ALT 3/4, PFL, & Tape IN
M1224FX SPECIFICATIONS
