©American Audio® - www.AmericanAudio.us - CDI-100 Mp3 Instruction Manual Page 13
GENERAL FUNCTIONS AND CONTROLS (Cont.)
D. LCD DISPLAY PANEL (FIGURE 5)
23. PLAY/PAUSE INDICATOR - Either the play
or pause indicator will glow depending which
mode you are in.
24. MP3 INDICATOR - This will indicate that a
Mp3 disc is loaded in the drive.
25. ELAPSE
D INDICATOR - This indicator is in
direct reference to the TIME DISPLAY (31). When
"ELAPSED" is indicated in the LCD DISPLAY (1),
the TIME DISPLAY (31) in the LCD will define the
single track's elapsed time. The time mode is
changed by the tapping on the TIME BUTTON
(2).
26. TOTAL/REMAIN INDICATOR - This indicator
is in direct reference to the
TIME DISPLAY (31).
When "TOTAL" and "REMAIN" are indicated in
the LCD DISPLAY (1) the TIME DISPLAY (31) in
the LCD (1) will define the total disc remaining
time. The time mode is changed by the tapping
on the TIME BUTTON (
2).
27. SINGLE INDICATOR - This indicates that the
CD drive is in single play mode, the track will
play once and return to CUE mode. If the single
indicator is not on the unit is in continuous mode
In continuous mode the drive will play all the
remaining tracks on the disc. Once the remain
-
ing tracks have ended the unit will return to cue
mode
28. REMAIN INDICATOR - This indicator is in
direct reference to the TIME DISPLAY (31). When
"REMAIN" is indicated in the LCD DISPLAY (1)
the TIME DISPLAY (31) in the LCD will define the
current track's remaining time. The time mode is
changed by the tapping on the TIME BUTTON
(2).
29. LOOP INDICATOR - Appears when a LOOP
is engaged.
30. PITCH METER - This meter will display the
pitch percentage applied by the
PITCH SLIDER
(4).
31. TIME DISPLAY - These indicators detail the
Minutes, Seconds, and Frames. The meter will
display either the elapsed or remaining time of a
track.
32. TIME BAR INDICATOR -
This bar gives a
visual approximation of a track's or disc's remain
-
ing time. This bar will begin to flash when a CD
is ending, or a track if the unit is in "SINGLE"
mode.
33. TRACK DISPLAY - This indicator describes
which track or folder is currently cued or is play
-
ing.
23
Figure 5
24 27 2825 26
30
3132
33
29
