American DJ® - www.americandj.com - Accu LED MH Instruction Manual Page 11 American DJ® - www.americandj.com - Accu LED MH Instruction Manual Page 12
Accu LED MH System Menu Accu LED MH System Menu
ADDRESS MENU -
AOO1 - A511 (Value) - This is where you set the DMX address of
the unit.
TEST MENU -
T-01 - T-XX (Test) - Tests the functions of each channel. There
are nine channels. Note: Some channels cannot be tested.
PLAY MENU -
RUN - Runs the unit as a “master” or in a stand alone mode. The
unit will run a internal program mode.
AUDI (Audio) - Runs the unit as a “master” or in a stand alone,
sound active mode.
AUTO - This is a precaution mode in case the DMX signal is lost.
There are four settings to choose from:
• “Hold” - This is the default setting, which in case the signal is
lost the xute will “hold” at the last setting.
• “Close” - The xture will return to its “home” standing.
• “Auto” - The xture will go into Auto mode and run a pre-pro-
grammed show.
• “Audi” - The xture will go into Sound Active mode.
RESE (RESET) MENU -
ALL - Resets all the motors in the unit.
SCAN - Resets the motors that control pan/tilt.
TIME MENU -
LIFE - Displays the xtures total running time.
CLMT - Clears the xture running time.
RPAN (REVERSE PAN) MENU -
ON/OFF - When “On” is chosen it will reverse the pan.
0
ADDR
AXXX A001
Indicate the staring DMX address
A001 also is the setting for slave
1
TEST
T-01~T-XX
Automatically test the function
RUN
MSTR/ALON
Runs fixture as “master” or “alone” for auto
AUDI
MSTR/ALON
Runs fixture as “master” or “alone” for audio
2
PLAY
AUTO
Clos/ Hold/Auto/Audi
Runs fixture for no DMX
ALL
Reset all motors and returns fixture to home
3
RESE
SCAN
Reset only motors for pan/tilt
LIFE
0000~9999
Displays the total fixture running time
4
TIME
CLMT
Clear fixture running time
5
RPAN
ON/OFF
Reverses the pan movements
6
RTLT
ON/OFF
Reverses the tilt movements
7
FINE
ON/OFF
Switch between 16 bit/8 bit
8
MIC
M-XX
Mic sensitivity
VALU
D–XX D-00 (DXXX)
Display the DMX512 value of each channel
D ON
ON/OFF
Display turn off after 2mins
9
DISP
FLIP
ON/OFF
This function will reverse the display 180
RDMX
ON/OFF
Change DMX address via external controller
SPEE
SP-1/SP-2
Movement Mode Select
DFSE
ON/OFF
Resets all the fixture functions to default
FEED
ON/OFF
Pan/tilt feedback (error correction) on/off
VER
V1.0~V9.9
Software version
CODE
CXXX
Fixture code *code is “C050”
10
SPEC
ADJU
CH01~CH30
XXXX(-128~127)
Motor Calibration
STEP
S–01 ~S–48
Set the amount of your program
C–01~C–30
0 1 XX(00~FFH)
3 0 XX(00~FFH)
Edit the channels of each scene
TIME
T XXX(001~999)
Time for each scene
SCXX
CEDT
ON/OFF
Edit program via controller
REC.
RE.XX
Auto Save
11
EDIT
RUN
ON/OFF
Program test
