MN-29423 • Rev 6 • 02/18 • S-Series Hot Food Holding Cabinets 37
Service
Model > 1000-UP 1200-UP
Item Description Part No. Qty Part No. Qty
1 Screw, 8-32 x 1/4" Phil SC-2459 30 SC-2459 32
2 Top Cover 1011534 1 1011653 1
3 Rear Trim 1011532 1 1011652 1
4 Rivet, Blind, #44, S/S RI-2100 44 RI-2100 44
5 Cordset 120V CD-33824 1 CD-33824 1
208240V CD-3551 1 CD-3551 1
230V CEE 7/7 CD-3922 1 CD-3922 1
230V CH216P CD-36231 1 CD-36231 1
230V BS 1363 CD-33925 1 CD-33925 1
230V AS/NZS 3112 CD38149 1 CD38149 1
6 Bushing, Straight, Strain Relief BU-3964 1 BU-3964 1
7 Bushing, 1-1/8" Snap BU-3378 8 BU-3378 8
8 Insulation IN22364 1 IN22364 1
9 Side Panel 5015105 2 5015105 2
10 Caster, 5" (127mm) Rigid CS-24874 2 CS-24874 2
11 Caster, 5" (127mm) Swivel With Brake CS-24875 2 CS-24875 2
12 Bottom Panel 1009941 1 1011650 1
13 Screw, 10-32 x 3/4 Phillips Pan Hd SC-2071 4 SC-2071 4
14 Handle, Offset Mag Latch HD-27080 2 HD-27080 2
15 Screw, 10-32 x 1-1/2, NF, Phil, Flat M/S,18-8 S/S SC-2073 12 SC-2073 12
16 Screw, 10-32 x 3/4, NF Phil, Flat M/S, #18-8 S/S SC-2072 12 SC-2072 12
17 Hinge, 1-3/8 Offset, Pair, Chrome HG-22338 2 HG-22338 2
18 Solid Door (Standard) 5012801 2 5012663 2
Windowed Door (Option) 5012806 1 5012822 1
Door Gasket GS23796 1 GS23796 1
19 Side Rack SR-2120 4 —— ——
20 Front Trim, Control 5012113 1 5012345 1
21 Control CC-34970 2 CC-34970 2
22 Switch Cover (230V only) CV38297 1 CV38297 1
23 Switch, Rocker, 125-277V, 20A SW-34769 2 SW-34769 2
24 Panel, Overlay PE-29394 1 PE-29395 1
25 Electric Chassis 5012122 1 5012122 1
26 T-Block BK-3019 1 BK-3019 1
27 Gaskets, Adhesive, .125 x .375 [Linear Ft] GS-23622 1 GS-23622 1
28 Bracket, Sensor Mounting 1493 2 1493 2
29 Block, Sensor BK29605 2 BK29605 2
30 Screw, 6-32 x 1/2, NC Phil, Flat SC-2254 2 SC-2254 2
31 Sensor, Oven Temperature SN-38111 2 SN-38111 2
32 Non-Product Probe Seal 1006871 2 1006871 2
33* Inner Back Panel 1011529 2 1011654 2
34* Breaker Switch Cutout Cover 1011697 1 1011397 1
35* Nut, M4-0.7 Hex 18-8 NU-22286 4 NU-22286 4
36* Nut, Hex #8-32 NU-2296 2 NU-2296 2
37* Nut, 6-32 Hex, S/S NU-2361 8 NU-2361 8
38* Plug, 3/8" Hole PG-25574 3 PG-25574 3
39* Screw, 10-32 x 1/4 Pan Hd Ground SC-2190 1 SC-2190 1
40* Screws, M4-0.7 x 6mm Phil SC-22271 4 SC-22271 4
41* Screw, 1/4-20 x 1/2, Nc Slot Rnd SC-2332 4 SC-2332 4
42* Screw, 6-32 x 1-1/4" Round Hd SC-2365 2 SC-2365 2
43* Screw, 10-32 x 1-3/4, NF, Phil, Flat M/S,18-8 S/S SC-29387 8 SC-29387 8
44* Spacer, Snap-In, 7/16", Control SP-29392 12 SP-29392 12
*Pan Slide —— —— SR-24447 16
*Pan Slide Rail —— —— 1011741 8
45* Tape, 1/2" Wide x 25 Mil VHB TA-24637 2 —— ——
46* Washer, 6-32, Flat, Nylon WS-23148 8 WS-23148 8
47* Washer, Star Lock WS-2467 1 WS-2467 1
*Not shown
Double Compartment - 1000-UP, 1200-UP
