Alfatron ALF-12X-BC
27
g) Password: Set the password
h) Click on the "Save" button to display the "Save successful" message, then set is to take effect
3) Video Parameters
Focus: Focus Mode: Set the focus mode (the default is auto, manual is optional)
Focus range: Set the focus range (the default is centre, the upper and lower are optional)
Focus Sensitivity: Set the focus sensitivity (default is low, high and medium are optional)
a) Exposure: Exposure Mode: Set the exposure mode (the default is automatic, manual, shutter priority, aperture priority,
and brightness priority are optional).
Exposure compensation: Exposure compensation setting is active when in auto status (default is off).
Exposure compensation value: Set the exposure compensation value, valid when set in auto (default 0, -7
to 7 optional).
BLC: Set back light compensation, valid when it is auto status (default is off).
Anti-flicker: Set up anti-flicker mode, valid when in automatic, aperture or brightness priority (default
50Hz, closed, 60Hz optional).
Gain limit: set the gain limits, auto, active when it is status of aperture or brightness priority (default 3, 0-15
optional).
b) Dynamic range: Set the dynamic range (default 5, Off, 0 - 8 optional).
c) Shutter speed: Active when in manual or shutter-priority (default 1/100，1/25, 1/30, 1/50, 1/60, 1/90, 1/100, 1/120, 1/180,
1/250, 1/350, 1/500, 1/1000, 1/2000, 1/3000, 1/4000, 1/6000, 1/10000 optional).
d) Aperture value: Set the aperture value, active when it is status of manual or aperture-priority (default F1.8, closed, F11, F9.6,
F8.0, F6.8, F5.6, F4.8, F4.0, F3.4, F2.8, F2.4, F2.0, F1.8 optional).
e) Brightness: Set the brightness value, active when it is a state of brightness priority (default 7,0-23 optional).
f) Color: White balance modes: Set the white balance mode (the default automatic, 3000K, 4000K, 5000K, 6500K,
manual, One-push optional). Note: Click the “Correction” button when selected the One-push white balance
mode.
Red Gain: Set the red gain, effective when in manual (default 255,0-255 optional).
Blue Gain: Sets the Blue gain, effective when in manual (default 199,0-255 optional).
Saturation: Set the saturation (default 80%, 60%, 70%, 80%, 90%, 100%, 110%, 120%, 130%, optional).
Color: Set the chrome (default 7,0-14 optional).
Auto white balance Sensitivity: Sensitivity Auto white balance settings (default is low, high, medium optional).
R
ed Gain. Set Red Gain. Only effective when white balance mode is manual (default 255, 0~255 optional)
Blue Gain. Set Blue Gain. Only effective when white balance mode is manual (default 255, 0~255 optional)
g) Image: Brightness: Set the brightness (default 6, 0-14 optional).
Contrast: Set the contrast (default 8, 0-14 optional).
Sharpness: Sets the sharpness value (default 7,0-15 optional).
Black and white mode: Set black and white mode (default color, black/white optional ).
Gamma: Gamma value setting (default, 0.45,0.50,0.52,0.55 optional).
Flip Horizontal: Set Flip Horizontal (default Off, On optional).
Flip Vertical: Set vertical flip (default Off, On optional).
h) Noise Reduction: 2D Noise Reduction: Set 2D noise reduction level (default Auto, 1-7 and Off optional).
3D Noise Reduction: Set 3D noise reduction level (default 5, 1-8 and Off optional).
