Alfatron ALF-12X-BC
26
d) Click the Save button to make settings effective.
2) Audio Configuration
a) Switch: Enable / disable audio.
b) Compressing format: Set audio compressing format and the device will reboot automatically after change (default
MP3,PCM,AAC optional)
c) Sampling frequency: Set sampling frequency and the device will reboot automatically after change (default
44100,16000,32000 and 48000 optional)
d) Sampling precision: Set sampling precision (default 16bits)
e) Compressing code rate: Set audio compressing code rate (default 64bits, 32,48,96,128bits optional)
f) Click “Save” button and the settings become effective when noting “Saved successfully”
4.2.5. Video configuration
1) Video encoding
a) Code stream: It will use a different code stream when setting different video output format. (Main stream and Secondary
stream)
b) Compressing format: Set video compressing format, then device restarts automatically (Main / Second code stream default
H.264, H.265 optional)
c) Video size: Set resolution, then device restarts automatically (Main stream default: 1920*1080, 1280*720 optional, Secondary
stream default: 640 * 320, 320 * 180, 1280 * 720, 1920*1080 optional)
d) Stream Rate control: Set rate control mode, then device restarts automatically (Primary / secondary stream default: variable bit
rate, fixed rate is for option)
e) Image quality: Set image quality (default for Primary stream is better image, secondary stream default is bad image. Best,
better, good, bad, worse, worst optional.
g) Rate (Kb / s): Set the video bit rate (main stream default: 4096Kb / s, 64-12288Kb / s optional; secondary stream default
1024Kb / s, 64-10240Kb / s optional)
h) Frame rate (F / S): Set the video frame rate (primary / secondary stream default: 25F / S, primary stream 5-30F/S optional,
secondary stream 5-30F / S optional)
i) Keyframe interval: Set the key frame interval (primary / secondary stream default: 75F, primary / stream 1-300F optional.
secondary stream 1-150F optional)
j) Name of Stream: User can revise the name of stream when obtaining rtsp or rtmp stream; main stream (default live/av0),
secondary stream (default live/av1). Note: usually remain the live and revise the parts thereafter.
k) Click on the "Save" button to display the "Save successful" message, then set is to take effect.
2) Flow Post
a) Switch: To turn on or off the main / secondary stream
b) Protocol: Primary / Secondary stream both use RTMP protocol
c) Host Port: Server port number (default 1935, 0-65535 optional)
d) Host Address: Server IP addresses (default 192.168.5.11)
e) Flow Name: Choose a different stream name (live / av0, live / av1 optional)
f) User: Set the user name.
