ALFATRON ALF-5/10/12/20X/30X-CAM
30
NTP Server Port: Sets the NTP server port (default 123).Valid after setting NTP server synchronization.
Set the time manually, Effective when setting manually.
Click on the "Save" button, it will be valid when display "Save successful".
3) User Management
Select users: Set the user type (the default administrator,Common User 1,Common User 2 optional)
User name: set the user name (Select User Administrator default admin; select a common user1 default user1; to select a common
user 2 default user2; the user can modify their own)
Password: Set a password(Select User Administrator default admin; select a common user1 default user1; to select a common user 2
default user2; the user can modify their own).
Password confirmation: Confirm the input passwords are the same or not.
Click on the "Save" button to display the "Save successfully" message, then the set is to take effect.
Note: Please note the case-sensitivity of the user name and password.
If login page by a common user’s name and password, one does not have configuration privileges but can only operate to preview,
playback, logoff.
4) Version upgrade
MCU version V2.0.0.16 2015-12-18
Camera version V2.0.0.16 2015-12-18
Focus version V2.0.0.6 2015-12-11
Users only read the version information above which is consistent with the menu version but can not modify. Different types of
machines have different information.
Update file:
Click "Browse ..." installation, to select the upgrade file in the pop-up window.
Click on the "Upgrade" button, the upgrade dialog will appear. the device will reboot automatically after the update successfully.
(Note: make sure the power and network are keeping connected during the process. or the upgrade will fail)
Note: After the version upgrade is complete, you need to restore factory defaults; a, through web to restore the factory default
configuration; b, through the recovery menu; c, remote control shortcut * # 6;
Choose one of the above three ways. I chose the IP accounts, passwords also need to be restored to the default.
5) Restore factory setting
Click on the pop-up "Restore Factory Defaults" button and choose “yes” or “no”, then the device will restart automatically and restore
the factory setting.
6) Reboot
Click on the pop-up "Reboot" button and choose “yes” or “no”, then the device will restart automatically
4.2.8
Logout
Point "Logout" pop-up "Confirmation" dialog; select "Yes" or "No", choose “Yes” to exit the current page and return to the user login
interface again.
4.2.9
Wireless network
If the user's equipment has a wireless network module, Web page "Network Configuration" has "Wireless
Network" configuration page, the specific configuration is as follows:
1）Network settings
Wireless network configuration:
Network interface enables: can check, to set the following items after checked.
DHCP: can check, if check, it can obtain IP automatically.
IP address: set wireless WIFI IP(default 192.168.1.250, if checked DHCP, IP could be assigned
automatically)
Note: wireless IP address can not be in the same segment with a wired IP address.
Subnet Mask: Set the wireless IP subnet mask (default255.255.255.0)
Default Gateway: Set the wireless IP default gateway (default 192.168.1.1)
SSID: The user can modify their own (the default-test)
Encryption: can check, the password can be set after checked.
Password: can set a password, the password can be changed if only checked encryption.
Click on the "Save" button to display "Parameter saved successfully" message, set to take effect
Note: SSID and password should be filled in correctly, otherwise, if restarted after the powered off, the wireless WiFi connection is
not successful.
2) WiFi hotlink
Click on the “search” button to search the WIFI hotspot.
