KONA Capture, Display, Convert v16.2 38 www.aja.com
Format Screen
The Format Screen shows the video format currently in use by the KONA
framebuffer (called the Device Format) and allows you to change it.
AJA Device Format
Video Format
This pull-down menu shows the currently selected Device format. If you select
an alternate value using the pull-down, it will change the format used by KONA’s
framebuffer.
When a change is made via the Video Format pull-down or by clicking an icon
and selecting a new format via a contextual menu, the block diagram will change
to reflect the new format.
Pixel Format
Use this pulldown menu to choose: YUV-10, YUV-8, RGB-10, or ARGB-8 or RGB-12.
RGB Range
The RGB Range pulldown menu allows you to select either Auto, Full-range (0-
1023) or SMPTE range (typically 64-940) for RGB color output.
NOTE: The AJA Control Panel software uses the abbreviation “sf” instead of “PsF” when
referring to “progressive segmented frame” formats. In the manual and in other
literature you may see either of these acronyms used interchangeably. Visually, it
is easier to recognize:
• “sf” for progressively segmented frame formats
• “p” for progressive frame formats
