10 GigE IP Mini-Converters SMPTE 2110 IP Transmit/Receive v2.5 25 www.aja.com
Update Tab Screen
Figure 20. eMini-Setup Update Tab Screen
Use this Update tab to install new firmware.
Installed - This field shows the version of the firmware currently installed.
Browse - This button opens a navigation window, allowing you to select the
firmware and load that version of firmware into the AJA device’s non-volatile
memory.
Progress - This indicator bar shows the progress of firmware installation.
Firmware Update Procedure
1. Check the AJA website for new firmware.
2. If new software is found, download it and uncompress the le archive (.zip).
3. Connect the device to a Mac or PC via a USB port on the computer.
4. Click the Update tab. Click the Browse button. Navigate to the rmware
(.ajas extension), open it, and conrm the update. Progress will be shown via
the “Progress” bar.
5. After the update, the AJA device must be rebooted by clicking on the
Reboot button in the prompt window.
See also: "Firmware Screen" on page 53 regarding the process of working with
firmware with the IP Mini-Converter's Web UI.
