ENGLISH
OVERVIEW
This Operation Manual aims to familiarize you with the technical data, design,
operating rules and storage of the Aiwa AVC-640 household electric vacuum
cleaner (hereinafter referred to as the vacuum cleaner, device).
NOTE: The illustrations provided in this Operating Manual are general schematic
images only.
UNPACKING THE DEVICE AND PREPARING FOR
OPERATION
1. Open the Package: Open the package carefully on a flat, stable surface.
2. Remove the polystyrene: Remove the polystyrene that protects the vacuum
cleaner.
3. Remove Accessories: Remove all accessories and integrated materials.
4. Remove the Vacuum: Lift the vacuum out of the box.
5. Remove the Plastic Bag: Remove the protective plastic bag from the vacuum
cleaner.
6. Save Packaging: Save the outer packaging for future transport.
Follow these steps to ensure that your vacuum cleaner and its accessories are
safely unpacked and ready for use.
ASSEMBLING THE VACUUM CLEANER:
ATTENTION! The components of the vacuum cleaner are made of plastic
and carefully assembled together. To avoid damaging the latches and
pull buttons, do not use force during assembly. Make sure the parts are
installed on the removal buttons without warping and that they are
firmly in place with the latches.
INSTALLING THE ELECTRIC FLOOR BRUSH AND METAL PIPE
1. When connecting:
• Hold the electric floor brush with your left hand in the direction shown in the
figure.
• Insert the brush mounting hole, located at the bottom of the metal tube,
vertically into the brush connector with your right hand.
• Press firmly on the push rod portion until you hear a "clicking" sound, indicati
ng
that the installation is complete.
Note: When assembling, make sure that the direction of the handle is
consistent with that of the floor brush. Align the driver pin with the plug.
(IMAGE 1)
2. When packing and storing, or when cleaning and vacuuming:
• If you need to remove the electric floor brush, press the brush release button as
shown in the figure.
• Pull the electric toothbrush in the direction shown in the figure. (IMAGE 2)
• Remove it from the installation hole.
INSTALLING THE BATTERY AND HANDHELD VACUUM CLEANER
• Hold the handheld vacuum cleaner with one hand. (IMAGE 3: A- Battery guide
rail)
• With your other hand, hold the battery pack, align it with the guide slot on the
body, and engage the battery pack in the direction of the arrow shown in the
figure.
