59
OUI of Voice VLAN
OUI represents a MAC address field. Its address can be calculated based on the 48-
bit MAC address and the corresponding bit of mask. The number of bits of ingress
MAC address and matching OUI is determined by the length of the all “1”-bit in the
mask. For example, if the MAC address is 1-1-1 and the mask is FFFF-FF00–0000,
the result of execution and calculation of MAC address and corresponding mask,
namely OUI, will be 0001–0000–0000. If the first 24 bits of the ingress MAC address
are matched with those of OUI, the enabled Voice VLAN interface identifies the data
flow and the ingress device as the Voice Data flow and voice device respectively. Voice
VLAN is divided for user Voice Data flow. Voice VLANs are created to connect the
interfaces linked with voice devices to transmit the Voice Data inside in a centralized
way. Voice Data and non-Voice Data often exist in the same network. Voice Data needs
a higher priority than other business data during transmission to reduce the possible
delay and packet loss.
1. Click the “VLAN > Voice VLAN > Property” in the navigation bar as follows.
Interface data are as follows.
Configuration Items
Description
State
Check and enable the Voice VLAN
VLAN
Specify the VLAN ID added ranging from 1 to 4,094, e.g. 1-
3, 5, 7 and 9, with VLAN 1 by default. Other VLANs must be
added in an untagged way to the port needing links.
CoS / 802.1p Remarking
Whether to redefine the Voice VLAN message priority or
not
Aging Time
Table aging time
