58
Interface data are as follows.
Configuration Items
Description
Port
Port No. to be configured
Mode
VLAN mode of port
Hybrid: port in this mode serves as the member of Tagged
and Untagged ports of VLANs
Access: port in this mode serves as the only member of
VLAN
Trunk: port in this mode serves as the only Untagged
member of PVID and the Tagged member of VLANs
Tunnel: Port Q-in-Q VLAN
PVID
Port native VLAN
Accept Frame Type
Message types received by ports
All: all messages
Tag Only: only Tagged messages will be received Untag
Only: only Untagged messages will be received
Ingress Filtering
A switch to decide to filter VLAN messages excluded at
the port
Uplink
Whether in uplink mode or not
TPID
Identification No. of VLAN Tag
7.2 Voice VLAN
Traditionally, ACL (Access Control List) will be applied to distinguish Voice Data and
QoS (Quality of Service) will be used to ensure transmission quality, thus enhancing
the priority. In order to simplify user configuration and facilitate voice flow management,
Voice VLAN emerges. Enabled interface judges whether it is Voice Data flow or not
according to the source MAC address field accessing the interface data flow. The
message in the source MAC address is the Voice Data flow, which confirms to the OUI
(Organizationally Unique Identifier) of the voice devices that are configured by the
system. The interfaces receiving Voice Data flow will automatically transmit to Voice
VLAN, thus simplifying user configuration and Voice Data management.
