AirLive ONU-10XG(S)-AX304P-2.5G User Guide

19

IPv6: WAN connections use IPv6 protocol.

IPv4 / IPv6: WAN connections use both IPv4 and IPv6 protocol.

IP Mode

DHCP: Automatically obtain an IP address from your ISP

Static: Set the IP address manually

PPPoE: Select this option if your ISP uses PPPoE

Enable Vlan

unchecked: In this wan connection, the packets transmitted by the PON

port without VLAN tag.

checked: In this wan connection, the packets transmitted by the PON

port with VLAN tag.

Vlan ID: input the VLAN ID you want to set.

802.1p: select the port priority you want to set.

MTU

MTU: max transfer unit.

Default Value: 1492 in route PPPoE mode, 1500 in other modes.

NAT

checked: enable NAT function

unchecked: disable NAT function

Request DNS

Enable: DHCP server assigns DNS.

Disable: set DNS manually.

Service Mode

Service mode indicates what the wan connection is used for.

E. g.: If this wan connection is used for VoIP, you should select the

service mode which contains VOIP, such as

TR069_VOIP_INTERNET, TR069_VOIP, VOIP or

VOIP_INTERNET.

Disable LAN DHCP

Checked: LAN DHCP will not work at the port which binds with the

WAN.

Unchecked: LAN DHCP will work at the port which binds with the

WAN.

Bind Port

Showing which LAN port or SSID the wan connection has included.

3.3.1.2 NAT Config

This page allows you to set NAT type.

Figure 3-3-3:NAT config
