20 AGM Global Vision
2. Install the mount on the Picatinny/ Weaver rail so that the stops
(C) slide into the transverse slots on the rail.
3. Affix the mount to the rail by locking the levers (B).
4. Verify that the clamping devices are firmly holding the mount. If
necessary, adjust each clamping device’s lever-cam lock as
detailed below:
1) Remove the QR mount from the rail.
2) With the clamping device unlocked, push the cam (D) towards
the arrow, which will cause the nut (E) to slide out of its hole.
3) To tighten/ loosen the clamping device, push down on the
cam (D) and turn the nut (E) CW/ CCW respectively, in one-two
increments (see note below). Much like when the cam (D) is
released, backward-moving spring will cause the nut (E) to
slide back into its hole.
NOTE:
The eight-sided nut of the mount lever-cam lock will only fit into
their hole if turned in one of the discrete positions, using increments
equal to 360°/8.
4) Verify that the adjusted lever-cams lock securely hold the
weapon mounting rail.
5. Remove all screw (F) along with the ring halves (G) and (H) (you
can remove the QR mount from the rail for convenience).
6. Place the scope between the halves of the rings and slightly fixing
it with the screws (F) only enough to allow the scope to rotate and
move back and forth.
7. Place the QR mount with the scope mounted on the weapon rail
and affix it by locking the levers. Adjust the eye relief. Position the
scope far enough to keep your eye safe from recoil.
8. Turn on the power of the scope and activate the reticle.
9. With the rifle held level, rotate the scope until the reticle is
precisely vertical and horizontal.
10. Check the position of the scope and tighten the ring screws.
Ensure an even fit by alternately tightening the screws.
