AGM Global Vision16
A Picatinny/Weaver mount is secured to the Rattler-C V² with two screws
(Fig. 2-8, A). The recommended tightening torque for the fixing screws is
4-5.3 Nm (5.44-7.2 ft lb).
To install the Rattler-C V² on a Picatinny/Weaver rail, perform the following:
1. Unlock the clamping device of the clip-on mount by pushing down on the
lever holder (Fig. 2-8, B) and unlocking the lever (C).
2. Install the clip-on on the Picatinny/ Weaver rail so that the stop (D) slides into
the transverse slot on the rail.
3. Affix the clip-on to the rail by locking the lever (C).
4. Verify that the clamping device is firmly holding the Rattler-C V². If necessary,
adjust the clamping device’s lever-cam lock as detailed in part 2.1.15.
2.1.15 CLAMPING DEVICE ADJUSTMENT
To adjust the mount’s clamping device, do the following:
1. Remove the Rattler-C V² from the rail.
2. With the clamping device unlocked (as shown in Figure 2-8), push the cam (F)
towards the arrow, which will cause the nut (E) to slide out of its hole.
3. To tighten/ loosen the clamping device, push down on the cam (F) and turn
the nut (E) CW/ CCW respectively, in one-two increments (see note below).
Much like when the cam (F) is released, backward-moving spring will cause
the nut (E) to slide back into its hole.
NOTE:
The eight-sided nut of the mount lever-cam lock will only fit into their hole if
turned in one of the discrete positions, using increments equal to 360°/8.
4. Verify that the adjusted lever-cam lock securely holds the mounting rail.
2.2 MAIN FUNCTIONS
2.2.1 QUICK MENU
In the live view mode, press to show the Quick Menu. This menu allows you
to adjust the brightness and contrast settings of the thermal image.
2.2.2 BRIGHTNESS ADJUSTMENT
1. Press the MENU button to show the Quick Menu.
2. Press
or button to select Brightness menu item and press the
MENU button to confirm.
3. Press
or button to adjust the brightness. You can select one of ten
levels of the brightness to adjust the image lighter or darker.
4. Hold the MENU button
to exit a menu.
2.2.3 CONTRAST ADJUSTMENT
1. Press the MENU button to show the Quick Menu.
2. Press
or button to select Contrast menu item and press the MENU
button to confirm.
