EN9
www.afx-light.com
TempSensor
E2 Unconnected
TemperatureSen-
sor disconnected
1. Check wire connection of the temperature sensor
2. Replace temperature sensor
3. Replace main board
PCBtoohotE3 Main board too
hot
Stopoperatingthemachineuntilthemainboardtempe-
rature has turned to normal
Time remain E4 Insufcienttime Please scan new RFID card
Temp Over heat
E5
Heating pro-
tection due to
over-temperature
Stopoperatingthemachineuntiltemperaturereturnsto
normal. Alert will clear off automatically
Heat Fail E6 Heating process
fail
1. Inspect wire connection of heating board
2. Replace heating coil
3. Replace heating board
TipoverE7 Tip over alert Machine will activate tip over protection if the angle is
more than 45 degrees. The alert will clear off automati-
cally once the machine is back to normal position.
SubPCBuncon-
nected E8
Sub-PCBdis-
connected
1. CheckwireconnectionofSub-PCB
2. Replace sub-PCB
3. Replace main board
Illegal Card
MachineLocked
Machine locked
because the RFID
card is illegal or a
copy
The use of an illegal or copied RFID card will lock the ma-
chine. In that case, the seller will stop providing warranty
and after-sales service. To unlock the machine, please
contact your seller.
SPECIFICATIONS
Power supply .......................................................................................... 200-240V~50/60Hz
Consumption .................................................................................................................... 600W
Heating time ..............................................................................................................5 minutes
Granuleconsumption .......................................................................................... 20-25g/min.
Height of spark fountain ............................................Adjustablefrom1.5-5min10steps
Density ........................................................................................................................ 30-100%
Max. output duration. .............................................................................................30seconds
Powder tank capacity ....................................................................................................... 150g
Weight ................................................................................................................................... 8kg
Dimensions .............................................................................................. 215x250x330mm
IMPORTANT NOTE: Electric products must not be put into household waste. Please bring them to a recycling centre. Ask your local
authorities or your dealer about the way to proceed.
